YAYUAN Heavy Duty Garden Solenoid Valve 1.25″ 1.5″ 2″ 3″ | AC/DC

YAYUAN RL Series Solenoid Valves are engineered for large-scale agricultural irrigation, golf courses, parks, and industrial dust suppression. Available in 1-1/4″, 1-1/2″, 2″, and 3″ sizes with AC24V or DC12V options. Features high-strength glass-fiber reinforced nylon construction, anti-corrosion, manual flow adjustment, and water hammer damage prevention. Tested up to 15.5Bar for reliable high-pressure operation.

Heavy Duty Irrigation Solenoid Valve (1-1/4″, 1-1/2″, 2″, 3″)

YAYUAN RL Series Solenoid Valves are engineered for heavy-duty irrigation applications including commercial parks, large-scale agricultural farmlands, golf courses, and industrial dust suppression. Built with glass-fiber reinforced nylon, these valves ensure long-lasting durability and high-performance flow control under harsh conditions.

⭐ Key Features

Flow Control Adjustment: Manual throttle for precise flow regulation. Turn clockwise to decrease flow, counter-clockwise to increase. Supports manual override to turn the valve ON/OFF.
Rugged Construction: Made of high-strength glass-fiber reinforced nylon with stainless steel internal components and embedded brass nuts for ultimate anti-corrosion and cavitation resistance.
Anti-Water Hammer: Advanced reverse-flow design ensures smooth, gradual opening and closing, effectively preventing dangerous water hammer damage to pipelines.
Universal Compatibility: Multi-functional design seamlessly fits various smart irrigation controllers. Supports standard AC24V or energy-saving DC12V Latching pulse solenoid coils.

📊 Technical Specifications

Model & Size	Flow Rate Range	Operating Pressure	Fluid Temp	Material
1-1/4″ (EVA120 / EVD120)	6.18 – 20.30 m³/hr	0.5 – 8.0 Bar (Tested up to 15.5 Bar)	≤ 60°C	Body: Glass-Fiber Nylon Diaphragm: EPDM Rubber
1-1/2″ (EVA150 / EVD150)	6.81 – 22.70 m³/hr
2″ BSP Thread (EVA200 / EVD200)	9.08 – 34.05 m³/hr
3″ Heavy Flow (EVA300 / EVD300)	34.00 – 68.00 m³/hr
